In this article, we will learn how to solve Error extending volume Size Not Supported In Windows Server 2012 and Windows Server 2016.


Extend Volume Failed in Windows Server 2016/2012

When I tried to Extend Volume for a specific drive in Windows Server 2012 R2 by doing the following:

  • Server Manager > File and Storage Services.
Open server manager - file and storage services
  • Navigate to Disks > (I have unallocated free space (19.5GB)).
  • Right click on C Drive > Select Extend volume.
Extend Volume from server manager in windows server
  • The following dialog will be shown to set New size.
extend volume in windows server
  • When I set the New size and clicked OK, I got “Extend failed” as shown below:
extend volume failed in windows server
  • I clicked on Extend failed to find out the reason, I got Error extending volume Size Not Supported
Error extending volume Size Not Supported
Error extending volume Size Not Supported

Error extending volume Size Not Supported

The “Error extending volume Size Not Supported” usually occurs because there is a partition/drive between the original partition and the unallocated spaceThence, If you want to extend the operating system volume/drive, you should first make sure that there is no partition between the original partition and the unallocated space.


Solving Error extending volume Size Not Supported

To be able to extend the operating system drive, you will need to provide unallocated space beside the partition that you would like to extend it. but this means all data in that drive will be deleted. therefore, you will need to back up or move your data located on this partition before deleting it.

In our case, the drive beside the operating system partition is F:\ partition and the unallocated space is beside it, not beside the operating system drive, and our goal is making the unallocated space beside the drive that we need to extend it (C:\) as shown below:

Unallocated free space beside OS disk management

Extend Operating System Partition

  • First, you should create a new volume from the unallocated space that available for you.
Create a New volume In Windows Server
  • Move the data files from F:\ Drive to the newly created volume or any other drive that has sufficient space or back up it to an external hard disk.
  • Now, go back to delete F:\ Drive (the partition besides the operating system drive).
delete volume in Windows Server
  • Great, the unallocated space becomes beside the Operating System drive and you will be able to extend it now.
  • Now, try to extend the Operating System drive that should be extended properly.

You can also perform the extend operation through the disk management as mentioned at Windows Extend Volume Greyed Out in Disk Management in Windows Server 2016/2012


Conclusion

In conclusion, we have learned how to extend the operating system drive without facing “Error extending volume Size Not Supported” issue.

Applied To
  • Windows Server 2012 R2.
  • Windows Server 2016.
